Operating Voltage | AC 90-220V, 50/60Hz |
Installation Method | Panel-mounted or wall-mounted |
Waterproof Rating | IP65 |
Number of Sensors | Supports up to 4 sensors simultaneously |
Language | Chinese/English (customizable) |
Power Consumption | <5W |
Current Output | 2 channels, 4–20mA |
RS485 Output | Single output, supports Modbus-RTU/JSON protocols |
Relay Output | 2 normally open channels (10A 250VAC); one can be configured as a timer relay |
Data Storage | Stores up to 100,000 records by default (customizable) |
Operating Conditions | Temperature: 0-60℃, Humidity: ≤90% RH |
